Ohio Contact replacement crane controls for Square D Class 5010 30" Type F Series A. When you locate the product(s) of your choice, please call 800–310–5999 or click on the part number below to email inquiry for pricing, availability or questions you need answered!
| Item No. | OEM No. | Description |
|---|---|---|
| 1 | 50909-013-01 | Magnet Case Cover |
| 2 | 50909-020-01 | Terminal Shield |
| 7 | 51139-040-04 | Calibration Plate |
| 10 | 51001-067-06 | Manual Release Nut |
| 11 | 50502-003-32 | Washer |
| 12 | 50502-601-12 | Spring |
| 16 | 50909-014-01 | Magnet Case |
| 17 | 50909-011-51 | Armature Assembly |
| 18 | 29005-80830 | Bearing |
| 19 | 50909-009-50 | Shoe Lever Assembly, Inner |
| 21 | 51007-094-01 | Bracket |
| 25 | 50502-601-13 | Spring |
| 27 | 50502-052-16 | Spacer |
| 28 | 51007-046-01 | Bearing (Type F 30") |
| 29 | 51007-030-50 | Virtual Center Assembly, RH |
| 30 | 51007-030-51 | Virtual Center Assembly, LH |
| 31 | 50502-526-17 | Special Cap Screw |
| 33 | 50502-601-38 | Shoe Clamp Spring |
| 35 | 50909-006-50 | Connecting Rod Link, RH |
| 36 | 23003-00500 | Jam Nut, RH |
| 37 | 50909-005-01 | Connecting Rod |
| 38 | 50903-427-01 | Jam Nut, LH |
| 39 | 50909-006-51 | Connecting Rod Link, LH |
| 40 | 50909-005-50 | Connecting Rod Assembly |
| 41 | 50909-008-50 | Shoe Lever Assembly, Outboard |
| 42 | 50903-401-20 | Pin |
| 43 | 50903-402-04 | Locking Pin |
| 46 | 50909-004-50 | Brake Shoe Assembly |
| 47 | 50903-808-57 | Brake Block |
| 49 | 50909-003-50 | Brake Shoe Assembly |
| 50 | 50909-001-01 | Lining Wear Indicator |
| 53 | 50909-010-50 | Shoe Support Lever Assembly |
| 54 | 51007-021-01 | Manual Release Screw |
| 56 | 51007-035-01 | Non-Magnetic Spacer |
| 57 | 50909-015-01 | Armature Gap Indicator |
| 61 | 50903-401-13 | Pin |
| 62 | 51007-027-51 | Torque Screw Assembly |
| 63 | 51007-027-02 | Torque Screw |
| 64 | 50502-051-28 | Spacer |
| 65 | 23690-01580 | Thrust Washer |
| 66 | 50502-003-30 | Washer |
| 69 | 50502-551-03 | Locknut |
| 70 | 51007-027-01 | Torque Screw Plate |
| 71 | 50502-003-31 | Spring Thrust Plate |
| 72 | 51007-040-01 | Operating Spring |
| 73 | 50903-401-21 | Outer & Support Lever Pin |
| 74 | 50909-007-50 | Frame Assembly |
